MaxiBeam

CREATIVE LIGHTWEIGHT FEATURE BEAM SYSTEM



Do you find it tricky to integrate wall and ceiling systems?

Create beautiful ceilings and walls with perfect design flexibility.

We know from experience that specifying wall and ceiling systems involves the coordination of other building elements and services as well as acoustic performance needs. Integrating M&E into ceilings takes time and can be frustrating.

We help solve our clients’ concerns by creating visual and functional walls and ceilings with seamless integration.

How we do help solve your challenges?

Overview

The benefits of MaxiBeam

  • 5 Standard profile sizes
  • Hard-wearing laminate options, produced in a variety of wood-style species
  • Modular system for easy installation
  • FR finishing
  • Acoustic solutions
  • Available as FSC® Certified
  • Fully finished, with no on-site cutting
  • Concealed fixings
  • Full access to services where required
  • Bespoke and exclusive beam option sizes
  • Integrated lighting
  • Tailor-made shaping and angled ends

Applications

MaxiBeam is custom-made to your specific requirements providing a modern creative vision.

MaxiBeam can be used on:

  • Ceilings
  • Suspended Rafts
  • Walling Systems
  • Vertical Screens
  • Combinations of these applications (like wall to ceiling).

Service Integration

We help solve the complexities in wall and ceiling integrations with 3D Modelling and detailed drawing. MaxiBeam is routinely used with seamless access and service integration.

  • Full Removable Access to Void
  • Access Hatches to specific locations
  • Hidden Doorways
  • Lighting
  • HVAC Grilles
  • Smoke Detectors & Sprinklers
  • Av Screens & Gabling

Create a beautiful beam system that adds real interest to walls and ceilings.

When creating impact MaxiBeam can add several dimensions to the spatial environment from linear lines of parallel beams to an eclectic mix of contrasting directions, dramatic angles and vertical screen beams. As a lightweight beam, installers love MaxiBeam due to its quick and simple installation, low weight and easy integration of services.



Use a design flexible lightweight beam that can be integrated with M&E services.

The flexibility of MaxiBeam helps designers overcome common concerns and frustrations through an easy-to-specify and install design. MaxiBeam is a high-performing system with its seamless and easy integration of services and creative flexibility. When it comes to your wall and ceiling needs, our experience and technical backup support the creation of stunning interiors.

Overview Sizes Finishes Technical Specs Contact form Gallery

Sizes

We provide tailored designs of bespoke beams for each product individually. MaxiBeam also comes in standard sizes and thicknesses. It typically comes in lengths of up to 2.85m. Infinite beam lengths are created using our discreet end-to-end joiner system.

HEIGHT / DEPTH:

100mm

THICKNESS:

‎50mm

LENGTHS:

(Single Beams):

Up to 2980mm

(Infinite Lengths):

Created using our discreet End-to-End joiner system

APPROX WEIGHT:

3.1 kg / per lm

TYPICAL CENTRE VARIANT:

100 - 250mm

‎ ‎

TYPICAL SPACING VARIANT:

50-210 mm

Style: 100mm

We provide tailored designs of bespoke beams for each product individually. MaxiBeam also comes in standard sizes and thicknesses. It typically comes in lengths of up to 2.85m. Infinite beam lengths are created using our discreet end-to-end joiner system.

HEIGHT / DEPTH:

125mm

THICKNESS:

50mm

‎ ‎

‎ ‎

LENGTHS:

(Single Beams):

Up to 2980mm

(Infinite Lengths):

Created using our discreet End-to-End joiner system

APPROX WEIGHT:

3.5kg / per lm

TYPICAL CENTRE VARIANT:

125-300mm

TYPICAL SPACING VARIANT:

‎75-260mm

‎ ‎

Style: 125mm

We provide tailored designs of bespoke beams for each product individually. MaxiBeam also comes in standard sizes and thicknesses. It typically comes in lengths of up to 2.85m. Infinite beam lengths are created using our discreet end-to-end joiner system.

HEIGHT / DEPTH:

150mm

THICKNESS:

50mm

‎ ‎

LENGTHS:

(Single Beams):

Up to 2980mm

(Infinite Lengths):

Created using our discreet End-to-End joiner system

APPROX WEIGHT:

3.9kg / per lm

TYPICAL CENTRE VARIANT:

150-375mm

TYPICAL SPACING VARIANT:

100-335mm

Style: 150mm

We provide tailored designs of bespoke beams for each product individually. MaxiBeam also comes in standard sizes and thicknesses. It typically comes in lengths of up to 2.85m. Infinite beam lengths are created using our discreet end-to-end joiner system.

HEIGHT / DEPTH:

200mm

THICKNESS:

50mm

‎ ‎

LENGTHS:

(Single Beams):

Up to 2980mm

(Infinite Lengths):

Created using our discreet End-to-End joiner system

APPROX WEIGHT:

5.1kg / per lm

TYPICAL CENTRE VARIANT:

200-400mm

TYPICAL SPACING VARIANT:

150-360mm

Style: 200mm

We provide tailored designs of bespoke beams for each product individually. MaxiBeam also comes in standard sizes and thicknesses. It typically comes in lengths of up to 2.85m. Infinite beam lengths are created using our discreet end-to-end joiner system.

HEIGHT / DEPTH:

285mm

THICKNESS:

50mm

‎ ‎ ‎

LENGTHS:

(Single Beams):

Up to 2980mm

(Infinite Lengths):

‎Created using our discreet End-to-End joiner system

APPROX WEIGHT:

6.3kg / per lm

TYPICAL CENTRE VARIANT:

200-600mm

TYPICAL SPACING VARIANT:

150-560mm

Style: 285mm

Finishes

Our factory-applied finishing solutions provide designers with a fantastic spectrum of colours and effects. Ideas are limitless with our finishes, allowing you the opportunity to breathe life into a project with dynamic options.

supalami

Supalami Swatches: Whitewashed Fir

Applied to the face of the beams with matching edging Supalami laminates provide a stunning finish without the cost of solid timber veneers. These finishes are available in Wood and Solid colours.



https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0000_Vtec_Supalami_Whitewashed-Fir.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0003_Vtec_Supalami_Pale-Oak.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0006_Vtec_Supalami_Cool-Oak.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0001_Vtec_Supalami_Vtec-Warm-Oak.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0008_Vtec_Supalami_Aged-Oak.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0004_Vtec_Supalami_European-Walnut.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0002_Vtec_Supalami_Smoked-Oak.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0007_Vtec_Supalami_Black-Woodgrain_Edited.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_2024_0005_Vtec_Supalami_Crisp-White.jpg https://vtecgroup.co.uk/wp-content/uploads/2024/02/Supalami_Finishes_Custom_Colours_01.jpg

Solid Timber Swatches:

Supaveneer Swatches: Cherry

Beautiful natural timber veneers with a high quality, clear lacquer.

https://vtecgroup.co.uk/wp-content/uploads/2023/08/Solid-Timber_Finishes_0000_Cherry.jpg https://vtecgroup.co.uk/wp-content/uploads/2023/08/Solid-Timber_Finishes_0001_Walnut.jpg https://vtecgroup.co.uk/wp-content/uploads/2023/08/Solid-Timber_Finishes_0003_Ash.jpg https://vtecgroup.co.uk/wp-content/uploads/2023/08/Solid-Timber_Finishes_0004_Steamed-Beech.jpg https://vtecgroup.co.uk/wp-content/uploads/2023/08/Solid-Timber_Finishes_0005_Oak-02-NO-FR.jpg

Driftwood Swatches:

Custom

We can produce any other laminate or species veneer of your choice, as well as bespoke lacquer finishes including metallic.

Supacolour

Using RAL and NCS colour systems, we can create finishes in matt, satin, high gloss or factory-applied base layer in any colour.

Technical Support

Our Slats Beams & Acoustics pages contain a digital library that you can access for your technical queries. Download data sheets, brochures and specification guides to help you

Still Have Questions?

Visit our MaxiBeam FAQ where you can find answers to some commonly asked questions. Determine whether the MaxiBeam – Lightweight Feature Beam System is the best option for your project.

Specification Guide

Our easy step-by-step specification guide walks you through the MaxiBeam specification process. It provides all the information you need from beam ends, to install options. Use this tool to create your specification today.

Get In Touch

We love to hear your ideas and aspirations for your walls and ceilings and work with you to help you realise your vision. Our Teams help solve your concerns by creating beautiful and functional walls and ceilings with seamless integration at its core.

Let’s get you started, contact us so we can help.

Contact Form
